| page
edited 4/30/2005 |
|
|
| 1993 |
|
| Cavity |
Wire Color |
Description |
|
| A |
Red |
Generator feed to
instrument cluster |
|
| B |
Tan |
Oil pressure feed to instrument
cluster |
|
| C |
Brown |
Oil level feed to instrument cluster |
|
| E |
Gry |
(manual) clutch anticipate signal (V6
VIN S only) |
|
| F |
Gry |
Feed from fuel
pump and fuel pump relay to prime connector |
|
| G |
Dk Green/White |
Vehicle speed signal |
|
| J |
Dk Green/White |
Fuel pump relay control |
|
|
Dk Green |
Coolant temperature feed to instrument
cluster |
|
|
|
|
|
|
|
|
|
| 1994 |
|
| Cavity |
Wire Color |
Description |
|
| A |
Red |
Generator feed to
instrument cluster |
|
| B |
Tan |
Oil pressure feed to instrument
cluster |
|
| C |
Brown |
Oil level feed to instrument cluster |
|
| D |
Orange/Black |
Spark Retard Request |
|
| E |
Tan/Black |
Throttle Position Sensor Signal
(EBTCM) |
|
| F |
Tan |
Serial data signal |
|
| G |
Dk Green/White |
Vehicle speed signal |
|
| H |
Dk Blue/White |
(Automatic)
Performance switch signal
(Manual) Skip shift indicator control (V8 VIN P only) |
|
| J |
Dk Green/White |
Fuel pump relay control |
|
|
|
Dk Green |
Coolant temperature feed to instrument
cluster |
|
|
|
|
|
|
|
|
|
| 1995 |
|
| Cavity |
Wire Color |
Description |
|
| A |
Red |
Generator feed to
instrument cluster |
|
| B |
Tan |
Oil pressure feed to instrument
cluster |
|
| C |
Brown |
Oil level feed to instrument cluster |
|
| F |
Tan |
Serial data signal (VIN S only) see C105 for VIN P |
|
| G |
Dk Green/White |
Vehicle speed signal |
|
| H |
Dk Blue/White |
(Automatic)
Performance switch signal
(Manual) Skip shift indicator control (V8 VIN P only) |
|
| J |
Dk Green/White |
Fuel pump relay control |
|
|
|
Dk Green |
Coolant temperature feed to instrument
cluster |
|
|
|
| 1996 |
|
| Cavity |
Wire Color |
Description |
|
| A |
Red |
Generator feed to
instrument cluster |
|
| B |
Tan |
Oil pressure feed to instrument
cluster |
|
| C |
Brown |
Oil level feed to instrument cluster |
|
| E |
Pink |
Power feed from PCM ignition Fuse #13 |
|
| G |
Dk Green/White |
Vehicle speed signal |
|
| H |
Dk Blue/White |
(V6 Automatic)
2nd gear start indicator control
(V8 Manual) Skip shift indicator control |
|
| J |
Dk Green/White |
Fuel pump relay control |
|
|
|
Dk Green |
Coolant temperature feed to instrument
cluster |
|
|
|
| 1997 |
|
| Cavity |
Wire Color |
Description |
|
| A |
Red |
Generator feed to
instrument cluster |
|
| B |
Tan |
Oil pressure feed to instrument
cluster |
|
| C |
Brown |
Oil level feed to instrument cluster |
|
| E |
Pink |
Power feed from PCM ignition Fuse #13 |
|
| G |
Dk Green/White |
Vehicle speed signal |
|
| H |
White |
Skip shift indicator control |
|
| J |
Dk Green/White |
Fuel pump relay control |
|
| K |
Dk Green |
Coolant temperature feed to instrument
cluster |
|
|
|
|
|
